Being certified company; we offer consistent range of hydraulic surface grinder machine. We make use of high grade material to fabricate the machine. Our machines are fabricated by following international norms and conditions and tested as per IS 2743: 1992. We are tagged as major manufacturer, supplier and Exporter of the different kinds of the surface grinder machines. Our offered ranges of machines are most advantageous, engineered with high precision.

Hydraulic Surface Grinder Machine (PREMIER)

Our high precise range is available with different table size. Table sizes are range from 500mm X 1000 mm. highly precise operations are carried out due to guide rails which also lead noise less operations. Longitudinal travel of 1075 mm and cross transverse of 550 mm is provided to table. Speed of the table is about 18 m/min with power cross transverse of 1000mm/ min. Our hydraulic surface grinder machines are available with spindle.

It is loaded with anti-friction bearings and spring. Spindle center height is above table of 700 mm. Due to precisely machined spindle, movement of the machine made easy. Our machine contains 5 hp spindle motor support. It is provided with capacity of 1400 RPM. Due to our space saving method, machine is fabricated as fine, compact designed. It contains size of 2900mm X 2100 mm. an independent motor is provided for function of wheel head. Installation of machine is very easy as well as least maintenance. Machine is highly preferred for its noiseless and vibration less operations.

Features:
  • Noiseless
  • Compact model
  • Anti-friction bearings
  • Vibration absorbing quality
  • Digital display
  • Dust collector
  • High precise works
Hydraulic Surface Grinder Machine PREMIER
Hydraulic Surface Grinder Machine (PREMIER)

Application : Hydraulic Surface Grinder Machine

Piston rings
Clutch and gears
Engine blocks
Washers
Various machine parts
Machine frames

Advantages of Hydraulic Surface Grinder Machine (PREMIER)

  • Toolroom Micro-Precision: Fine-feed handwheels and precision lead screws enable sub-micron vertical and cross feed adjustments.
  • Ultra-Smooth Hydraulic Reversal: Proximity-switch controlled hydraulic table reversal eliminates shock and chatter marks.
  • High Spindle Concentricity: Dynamically balanced spindle mounted on angular contact bearings guarantees smooth rotation.
  • Compact Industrial Footprint: High performance packed into a space-efficient design suitable for toolrooms and job shops.
  • Cost-Effective Operation: Energy-efficient motors and low hydraulic oil consumption deliver low operating costs.

FAQ'S Of Hydraulic Surface Grinder Machine (PREMIER)

1. What is a Hydraulic Surface Grinder Machine (PREMIER)? +The PREMIER model is a precision-engineered hydraulic surface grinder built for high accuracy, excellent surface finish, and reliable daily toolroom or production grinding operations.
2. What makes the PREMIER hydraulic surface grinder suitable for toolrooms? +Its rigid cast-iron construction, high-precision spindle bearings, micro-feed cross movements, and smooth hydraulic motion make it ideal for fine toolroom tolerances.
3. What is the surface finish quality achievable with the PREMIER model? +The PREMIER model can achieve high surface flatness and smooth surface finishes down to Ra 0.2 to 0.4 microns under optimal wheel and coolant conditions.
4. What coolant system is recommended for the PREMIER surface grinder? +A recirculating coolant system with magnetic separator or paper band filter is recommended to continuously remove metal swarf and keep workpieces cool.
5. Does the PREMIER surface grinder support manual and automatic feeds? +Yes, it features automatic hydraulic longitudinal travel combined with fine manual or motorized cross and vertical feeds for versatile operation.
6. How do you ensure high accuracy on a PREMIER hydraulic surface grinder? +Ensure proper wheel balancing, frequent wheel dressing, maintaining steady ambient room temperature, and using clean, correct-viscosity hydraulic fluid.
